PrimaX
GB
31
Relay Operation
Startup
If relays are used the alarm threshold will be displayed at startup
Menu Sequence
Relay Operation
[M-11] - Relay Info
(1) Press ENTER and select menu 11.
(2) Press ENTER button.
(3) Go through the information with the ENTER button.
It shows:
- The alarm threshold and if the alarm is activated with a rising or falling gas con-
centration.
- if an alarm would be latched.
- the alarm relay delay time in seconds.
- if the alarm relay is normally energised.
- the failure relay delay time in seconds.
- if the failure relay is normally energised.
Menu item Text Password?
M-11 Relay Info No
M-12 Relay Setup Yes
M-13 Relay Test Yes
