MSI Dyna-Link 2 - Standard Print Strings

38 MSI-7300 Operator’s Manual
6.2.1 Standard Print Strings
1 Current
Te n si o n
Fixed output length: 16. Leading zer
os suppressed except for the
LSD.
TTTTTTTspUUspMMMMMcrlf
TTTTTTT – tension data with -sign if necessary.
UU – units
MMMMM – tension mode which for “1” is either NET or GROSS
2 Net Tension Fixed output length:16. Leading ze
ros suppressed except for the
LSD.
TTTTTTTspUUspNETspspcrlf
3 Gross
Tensi o n
Fixed output length: 16. Leading zeros suppressed except for the
LSD.
TTTTTTTspUUspGROSScrlf
4 Tare We i ght Fixed output length:16. Leading zeros suppressed except for the
LSD.
TTTTTTTspUUspTAREcrlf
5 Total
We
ight
Fixed output length: 16. Leading zeros suppressed except for the
LSD.
TTTTTTTTTspUUspTTLcrlf
6 Number of
Samples
To
taled
Fixed output length: 16. Leading zeros suppressed except for the
LSD.
spspspspspsp
SSSSSSSspT- C N Tspcrlf
7 Current
Weight
Mode
Net, Gross, Peak, etc
spMMMMMcrlf
8/9 Carriage
Retur
n/
Line Feed
Used to add a space between print records.
crlf
Table 6-1. Standard Print Strings
In the string number entry screen, you can enter combinations of the standard print
strings. For example,
to get a NET GROSS TARE printout with a space between
records, simply enter “2349.”
Using SCCMP application (ScaleCore configuration management program),
custom
output strings are possible. See the ScCMP programming guide for details.
Note
ScCMP programming can be found on the CD included with the
product or can be downloaded from the MSI website.
The serial output is configured as 9600 baud, Xon/Xoff handshaking, no hardware
handshaking, 1 stop bit, no parity. Other baud rates are possible by special order only.
