48 MSI-7300 Operator’s Manual
7.2 Error Codes
The ScaleCore processor that is the heart of the MSI-7300 Dyna-Link2 detects errors and
generates error codes to aid in troubleshooting.
Table 7-2. Error Codes
Error Code Definition Comment
LcOFF LC Disabled A load cell was not enabled
2CAL In Cal The system is in calibration mode.
Do not send commands unrelated to
calibration.
unCAL Not Calibrated System has not been calibrated.
Error
Load
Overload Tension/Weight exceeds set
capacity +9d
Load Cell damaged or disconnected
Error
UnLd
Underload Tension/Weight is more than 20%
negative
Load cell damaged or disconnected
