MSSC Smart-Jet Plus - Counter Types and Configuration; Single Counter Setup; Box;Lot Counter Setup

24
Move the cursor to the each object and input the value. After all values are set, move the
cursor to Add counter here and press Enter to insert the counter into the message.
 Start: start number of counter.
 Current: current number that you would like to print immediately.
 Reset: end number of counter.
 Step: count step of counter.
 Up/Down: direction of counter. Up for increase number, down for decrease number.
 Fill zero: add 0 before each number like 09, 009, 0009…
 Add counter here: insert counter into the message.
Example
To print the following counter on each object:
001, 003, 005….101, 001, 003, 005 …
 Start: 1
 Current: 1
 Reset: 101
 Step: 2
 Up/Down: Up
 Fill zero: Enable
NOTES:
User can insert up to 6 independent counters in one message.
Box/Lot
Is a dual counter. This is used to count the box and the products in the box.
Move the cursor to the each object and input value. After complete setting for all objects,
move to Add counter here and press Enter to insert the counter into the message.
COUNTER 1
COUNTER 2
 Start: start number
 Current: current number
 Reset: end number
 Step: count step
 Up/Down: increase or decrease
 Fill zero: add 0 before each number
 Add counter here: insert counter
 Start: start number
 Current: current number
 Reset: end number
 Step: count step
 Up/Down: increase or decrease
 Fill zero: add 0 before each number
 Add counter here: insert counter
Example
Printing on certain package with a chain of digits, the first 3 digits are the number of the
box containing the package; the last 3 digits are the order of the package within the box,
let’s say there are 20 packages in the box.
Follow below steps to set counter:
