5. Tighten drain screws (2) and (3) with torque wrench to the specified torque.
Name Size Type Lubricant Value/Standard
Screw M26 x 1.5 Tightening torque (Engine oil) 100Nm +10Nm
Filling with new engine oil
1. Open cover on filler neck.
2. Pour oil in at filler neck up to "max." mark
at oil dipstick.
3. Close cap on filler neck.
4. Check engine oil level (→ Page 110).
M015695/03E 2013-03 | Task Description | 113
TIM-ID: 0000006152 - 008
