Main engine dimensions
Main engine dimensions
Length (A) 12V
approx. 2810 mm
Length (A) 16V
approx. 3280 mm
Width (B) 12V, 16V
approx. 1585 mm
Height (C) 12V, 16V
approx. 2027 mm
48
|
Technical Data
|
M015695/03E 2013-03
