Operating Instructions

Diesel engine

12 V 4000 C10, C10R, C11, C11R

12 V 4000 C20, C20R, C21, C21R

16 V 4000 C10, C11, C11R

16 V 4000 C20, C20R, C21, C21L

MS150049/02E

Table of Contents

Questions and Answers:

W
Wendy SnyderAug 12, 2025
What to do if MTU 16 V 4000 C21 does not turn when starter is actuated?
- C
  colonandreaAug 13, 2025
  If the MTU Engine does not turn when the starter is actuated, possible causes include a low or faulty battery (in which case you should charge or replace it, refer to the manufacturer's documentation), faulty cable connections (check if they are properly secured, refer to the manufacturer's documentation), faulty engine cabling or starter, faulty assemblies or loose connectors (perform a visual inspection, refer to the manufacturer's documentation), loose plug-in connections (check plug-in connections), or a blocked running gear (in which case you should contact service).
P
Paul PetersonAug 16, 2025
What to do if MTU 16 V 4000 C21 turns but does not fire?
- L
  Laura HowellAug 17, 2025
  If the MTU Engine turns but does not fire, it could be due to poor rotation by the starter because of a low or faulty battery. In this case, charge or replace the battery, referring to the manufacturer's documentation. It could also be due to air in the fuel system, in which case you should vent the fuel system.
D
Donna RandallAug 20, 2025
Why MTU 16 V 4000 C21 produces black exhaust gas?
- C
  Christopher RhodesAug 20, 2025
  If the MTU Engine produces black exhaust gas, it might be due to a clogged air filter (check the signal ring position of the service indicator) or a faulty injector.
M
Michael McmahonAug 25, 2025
What to do if MTU 16 V 4000 C21 fires unevenly?
- C
  Christine WilsonAug 25, 2025
  If the MTU Engine fires unevenly, it could be due to a faulty injector (replace it). Another cause may be air in the fuel system, so vent the fuel system.
R
Rebecca SimsAug 27, 2025
How to increase MTU 16 V 4000 C21 Engine speed to rated?
- E
  Elizabeth MelendezAug 27, 2025
  If the MTU Engine does not reach rated speed, the fuel prefilter might be clogged (clean or replace the filter element).
R
rwarrenAug 31, 2025
How to troubleshoot white exhaust gas from MTU 16 V 4000 C21 Engine?
- J
  Jason SimmonsAug 31, 2025
  If the MTU Engine emits white exhaust gas, it may not be at operating temperature, so run the engine to reach operating temperature. Another cause might be water in the fuel; in that case, drain the fuel prefilter.
V
vbellSep 4, 2025
Why is charge air temperature too high in MTU 16 V 4000 C21 Engine?
- J
  Jeffrey WyattSep 4, 2025
  If the charge air temperature is too high in your MTU Engine, the engine coolant treatment may be incorrect, so check it using the MTU test kit. Also, the air-intake temperature may be too high, so check the fans and intake/exhaust lines.
L
Lisa JohnsonSep 8, 2025
What causes blue exhaust gas from MTU 16 V 4000 C21?
- Z
  Zachary BushSep 8, 2025
  If the MTU Engine emits blue exhaust gas, it could be due to too much oil in the engine, so drain some engine oil. Another cause could be a clogged filter element in the oil separator, so replace it.
