MTU 16 V 4000 C21 - Engine - Main dimensions

3.6 Engine – Main dimensions
Engine model Length (A) Width (B) Height (C)
12 V 4000 Cxy approx. 2540 mm approx. 1620 mm approx. 1990 mm
16 V 4000 Cxy approx. 3010 mm approx. 1620 mm approx. 1990 mm
MS150049/02E 2012-11 | Technical Data | 39
TIM-ID: 0000002136 - 003
