7.5.3 Cylinder head cover – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Gasket
(→ Spare Parts Catalog)
Removing cylinder head cover
1. Clean very dirty cylinder head covers prior
to removal.
2. Remove screws.
3. Remove cylinder head cover with gasket
from cylinder head.
Installing cylinder head cover
1. Clean mating face.
2. Check condition of gasket, replace if necessary.
3. Place gasket and cylinder head cover on cylinder head.
4. Install cylinder head cover.
MS150049/02E 2012-11 | Task Description | 89
TIM-ID: 0000000923 - 006
