7.7.2 Injector – Removal and installation
Preconditions
☑ Engine shut down and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Installation and removal tool for injector
F6790161 1
Milling cutter
F30452739 1
Slotted screwdriver
F30452578 1
Torque wrench, 1-20Nm
F30044239
Torque wrench, 10-60Nm
F30452769 1
Torque wrench, 60-320Nm
F30452768 1
Assembly paste (Optimoly Paste White T)
40477 1
Grease (Kluthe Hakuform 30-10/emulsifier)
X00029933 1
Engine oil
WARNING
Fuels are combustible.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
CAUTION
Removal of all injectors.
Damage to component!
• Ensure that the high-pressure fuel accumulator is secured on the engine through two HP lines.
CAUTION
Cable damage during operation.
Fire hazard!
• Twist cables when installing.
• Ensure that cables do not touch components.
Preparatory steps
1. Close off fuel supply to engine.
2. Remove cylinder head cover (→ Page 89).
92 | Task Description | MS150049/02E 2012-11
TIM-ID: 0000000952 - 009
