7.17 Belt Drive
7.17.1 Drive belt – Condition check
Preconditions
☑Engine is stopped and starting disabled.
☑Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt Belt is oily, shows signs of over-
heating
Replace (→ Page 144)
Drive belt B Cracks on entire circumference
Drive belt C Chunking
M015695/03E 2013-03 | Task Description | 139
TIM-ID: 0000000920 - 010
