7.5.2 Valve clearance – Check and adjustment
Preconditions
☑Engine shut down and starting disabled.
☑Engine coolant temperature is max. 40 °C.
☑Valves are closed.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Feeler gauge
Y20098771 1
Torque wrench, 60-320 Nm
F30452768 1
Box wrench socket, 24 mm
F30039526 1
Engine oil
Preparatory steps
1. Remove cylinder head cover (→ Page 95).
2. Install barring device (→ Page 78).
3. The OT (TDC) marking (1) (if fitted) on the
flywheel must not be used for reference.
M015695/03E 2013-03 | Task Description | 91
TIM-ID: 0000000922 - 010
