7.1.2 Engine – Barring with starting system
DANGER
Unguarded rotating and moving engine components.
Risk of serious injury – danger to life!
• Before barring or starting the engine, ensure that nobody is in the danger zone.
• After working on the engine, check that all protective devices have been reinstalled and all tools
removed from the engine.
Engine – Barring with starting system
1. Release latch of connector X4.
2. Remove connector from engine governor.
3. Bar engine in unloaded condition: Press START button.
4. Let the crankshaft rotate until oil pressure is indicated.
5. Engine start is automatically interrupted when specified starting period has passed. If necessary, re-
start the engine after approx. 20 seconds.
6. Connect connector X4 to engine governor and latch in position.
80 | Task Description | M015695/03E 2013-03
TIM-ID: 0000000918 - 004
