11.Technical Specifications
Video Trigger
Modulation
Support standard NTSC, PAL and SECAM
broadcast systems
Line number range 1-525 (NTSC) and 1-625 (PAL/SECAM)
Pulse trigger
Trigger condition
Positive pulse:>, ,
Negative pulse:>, ,
Pulse Width range
30 ns to 10 s
For MP720106 the range is
8 bits mode 2 ns to 10 s
12 bits mode 4 ns to 10 s
14 bits mode 20 ns to 10 s
Slope Trigger
Trigger condition
Positive pulse:>, ,
Negative pulse:>, ,
Time setting
30 ns to 10 s
For MP720106 the range is
8 bits mode 2 ns to 10 s
12 bits mode 4 ns to 10 s
14 bits mode 20 ns to 10 s
Runt Trigger
Polarity Positive, Negative
Pulse Width
Condition
>, =, <
Pulse Width Range
30 ns to 10 s
For MP720106 the range is
8 bits mode 2 ns to 10 s
12 bits mode 4 ns to 10 s
14 bits mode 20 ns to 10 s
Windows Trigger
Polarity Positive, Negative
Trigger Position Enter, Exit, Time
Windows Time 30 ns to 10 s
For MP720106 the range is
8 bits mode 2 ns to 10 s
12 bits mode 4 ns to 10 s
14 bits mode 20 ns to 10 s
Timeout Trigger
Edge Type Rising, Falling
Idle Time
30 ns to 10 s
For MP720106 the range is
8 bits mode 2 ns to 10 s
12 bits mode 4 ns to 10 s
14 bits mode 20 ns to 10 s
144
Performance Characteristics Instruction
