4.Advanced User Guidebook
Source
Select CH1 as the trigger source.
Select CH2 as the trigger source.
Edge
Trigger on the rising edge of the input signal when
voltage level meets the specified trigger level.
Trigger on the falling edge of the input signal when
voltage level meets the specified trigger level.
Configure
Idle Time
Set idle time before the edge counting in Nth Edge
Trigger. Adjust M knob or click to set idle time
press panel button or click to
move cursor to choose which digit to be set. Available
range is 30ns-10s, default 100ns.
Edge Num
Set the edge number value of “N” in Nth Edge trigger.
Mode
Holdoff
Normal
Single
Holdoff
Acquire waveform even no trigger occurred
Acquire waveform when trigger occurred
When trigger occurs, acquire one waveform then stop
100 ns - 10 s, adjust M knob or click to set time
interval before another trigger occur, press
panel button or click move cursor to choose
which digit to be set.
Set Holdoff time as 100 ns
Alternate Trigger (Trigger mode: Edge)
Trigger signal comes from two vertical channels when alternate trigger is on. This
mode is used to observe two unrelated signals. Trigger mode is edge trigger.
Alternate trigger (Trigger Type: Edge) menu list:
Set vertical channel trigger type as edge trigger.
Source
Channel 1 as trigger signal.
Channel 2 as trigger signal.
Coupling
Block the direct current component.
Allow all component pass.
Slope
Trigger on rising edge
Trigger on falling edge
Acquire waveform even when no trigger occurs
49
