4.Advanced User Guidebook
Display
Format
Binary
Decimal
Hex
ASCII
Set the display format of the bus.
EventTable
ON
OFF
Select "ON" to display the event table.
Save
EventTable
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB storage
device.
How to Operate the Function Menu
The function menu control zone includes 8 function menu buttons: Measure, Acquire,
Utility, Cursor, Autoscale, Save, Display, Help and 3 immediate-execution buttons:
Autoset, Run/Stop, Single.
How to Implement Sampling Setup
Push the Acquire button, Acqu Mode, Length, PERF Mode and Intrpl is shown in
the bottom menu.
The description of the Acqu Mode menu is shown as follows:
Function Menu Setting Description
Acqu
Mode
Sample Normal sampling mode.
Peak Detect
Use to capture maximal and minimal
samples. Finding highest and lowest points
over adjacent intervals. It is used for the
detection of the jamming burr and the
possibility of reducing the confusion.
Average 4, 16, 64, 128
It is used to reduce the random and irrelevant
noises, with the optional number of averages.
61
CAN Decoding menu list:
MENU SETTING INSTRUCTION
Bus Type CAN Set bus type of decoding as CAN.
