4.Advanced User Guidebook
The description of PERF Mode menu is shown as follows:
Function Menu Setting Description
PERF Mode
8-bit
Set the vertical resolution (A/D)
12-bit
14-bit
(only for MP720106 )
When the sample rate <=250MS/s, ADC resolution is set to 12-bit by default;
When the sample rate >250MS/s, and both channels are turned on, ADC resolution is
set to 8-bit by default;
When the sample rate <250MS/s, and only one channel is turned on, ADC resolution
can be set to 8-bit or 12-bit in this menu.
Note: For MP720106 the selection of 8-bit, 12-bit or 14-bit is not affected by sample rate.
The description of the Intrpl menu is shown as follows:
Function Menu Setting Description
Intrpl
Sinx/x Use sine(x)/x interpolation
x Use linear interpolation
Interpolation method is a processing method to connect the sampled points, using
some points to calculate the whole appearance of the waveform. Select the appropriate
interpolation method according to the actual signal.
Sine(x)/x interpolation: Connect the sampled points with curved lines.
Linear interpolation: Connect the sampled points with straight lines. This method is
suitable to rebuild the straight-edged signals, such as square or pulse wave.
62
The description of the Record Length menu is shown as follows:
Function Menu Setting Description
Length
1000
Choose the record length
(Fo
r MP720106, 40M is available on both
single CH and double CH)
10K
100K
1M
10M
20M
40M (Single CH)
To Next Page
