multicomp pro MP720105 User Manual

11.Technical Specifications
Performance Characteristics Instruction
Measurement
Cursor
△V, △T, △T&△V between cursors,
auto cursor
Automatic
Period, Frequency, Mean, PK-PK, RMS,
Max, Min, Top, Base, Amplitude, Overshoot,
Preshoot, Rise Time, Fall Time, +Pulse
Width, -Pulse Width, +Duty Cycle, -Duty
Cycle, Delay A→B , Delay A→B , Cycle
RMS, Cursor RMS, Screen Duty, Phase,
+Pulse Count, -Pulse Count, Rise Edge
Count, Fall Edge Count, Area, and Cycle
Area.
Waveform Math
＋, －, *, / ,FFT, FFTrms, Intg, Diff, Sqrt,
User Defined Function, digital filter (low
pass, high pass, band pass, band reject)
Decoding Type
(optional)
RS232, I2C, SPI, CAN
Waveform storage 100 waveforms
Lissajous
figure
Bandwidth
Full bandwidth
Phase
difference
±3 degrees
Communication
port
Standard
USB, USB Host (USB storage:Trig Out(P/F)；LAN port
Optional VGA port and AV port
Counter Support
Trigger
Performance Characteristics Instruction
Trigger level range
Internal ±5 div from the screen center
EXT ±2 V
EXT/5 ±10 V
Trigger level
Accuracy (typical)
Internal ±0.3 div
EXT ± (10 mV + 6% of Set Value)
EXT/5 ± (50 mV +6% of Set Value)
143
Trigger
displacement
Ac
cording to Record length and time base
Trigger Holdoff
range
100 ns – 10 s
50% level setting
(typical)
Input signal frequency ≥ 50 Hz
Edge trigger
slope
Rising, Falling
