3.Junior User Guidebook
Gestures in Normal Mode
 Select a channel (CH1 or CH2 button): Touch the pointer on the left side of
corresponding channel to make it in selected state.
 Set the vertical position of the selected channel (Vertical Position knob): Swipe up
or down on the screen.
Touch to select the channel
Selected
Unselected
Control the vertical position
of the selected channel
 Set the trigger level of the source in trigger menu (Trigger Level knob): Swipe up
or down on the area nearby the trigger pointer on the right.
Control the trigger level of
the source in trigger menu
 Set the horizontal position (Horizontal Position knob): Swipe left or right on the
display area.
18
