11.Technical Specifications
General Technical Specifications
Display
Display Type 8" Colored LCD (Liquid Crystal Display)
Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels
Display Colors 65536 colors, TFT screen
Output of the Probe Compensator
Output Voltage
(Typical )
About 5V, with the Peak-to-Peak voltage ≥1 MΩ.
Frequency (Typical )
Square wave of 1 KHz
Power
Mains Voltage
100V - 240VAC RMS, 50/60 Hz, CAT Ⅱ
Power Consumption
＜
24W
Fuse 2A, T class, 250V
Battery (optional)
3.7V, 13200mAh
The battery can last approximately 2.5 hours after a full
charge.
Environment
Temperature
Working temperature: 0℃ - 40℃
Storage temperature: -20℃ - 60℃
Relative Humidity ≤ 90%
Height
Operating: 3,000m
Non-operating: 15,000m
Cooling Method Fan cooling
Mechanical Specifications
Dimension 340mm× 177mm×90mm (L*H*W)
Weight Approx. 2.6kg (without accessories)
Interval Period of Adjustment:
One year is recommended for the calibration interval period.
147
