4.Advanced User Guidebook
Each par
ameter name is a case-sensitive string of 4 bytes. The parameter value is at
least 4 bytes.
1.Format description of the file header:
1) HEAD
Parameter name
Meaning
Value
Comment
HEAD
Header size
4 bytes int
2) TYPE
Parameter name Meaning Value Comment
TYPE Model 12 bytes char
3) BYTE
Parameter name Meaning Value Comment
BYTE Data length in bit 4 bytes int
4) SIZE
Parameter name
Meaning
Value
Comment
SIZE
File size
4 bytes int
Used to check the file
integrity
5) VOLT
Parameter name Meaning Value Comment
VOLT
Voltage division,
divided by 400 is
ADC resolution.
(When the source is
CH1&CH2, it is CH1
voltage division.)
4 bytes float
The value indicates voltage
(the unit is mV), such as 200
mV.
6) SAMP
Parameter name
Meaning
Value
Comment
SAMP
Sample rate
4 bytes float
The unit is Sa/s.
7) ADCB
Parameter name Meaning Value Comment
ADCB ADC bit, ADC
resolution
4 bytes int 8-bit or 12-bit
8) CHAN
Parameter name Meaning Value Comment
CHAN Number of channels 4 bytes int 1 or 2
9) VOL2
Parameter name Meaning Value Comment
VOL2 Voltage division,
divided by 400 is
ADC resolution.
(When the source is
CH1&CH2, it is CH2
voltage division.)
4 bytes float The value indicates voltage
(the unit is mV), such as 200
mV.
80
