Installation
Ultima Hooklift 01/2020
41
Install the cable from hooklift through the existing
holes in the cabin and check the tightness of lead-in.
If the cabin has tilting mechanism then the cable
must be run around the tilting mechanism. Check
that the cable can’t get squeezed in the cabin con-
struction.
Power feed 10A. Use only free con-
nection place which does not have
other electric devices connected.
Additional warning lights,
See 6.1 DB harness
