Installation
Ultima Hoo
klift
01/2020
42
2GCC Bracket, Basic, Fixed
113170001 Basic Bracket, Fixed
2GCC Handle Bracket, Fixed
112992201 Base plate
113170201 Handle Bracket
Controller bottom screw
4 x M4x10
Max torque 1,1 (+0,4) ft
-
lb
41
43
