62 Part Number: WBL-95-156 REV002
Maintenance Section 4
5. Enter the Service screen from the Touch To Start Screen by
touching these three corners one at a time and entering
the Service password into the password screen.
1 2
3
6. Evacuate all water from the reservoir and evaporator by
entering the Service screen> Service Outputs> Cleaning
and toggling the Ice Maker Dump Valve ON until all water
has been emptied from the system then toggle OFF.
7. Empty all ice from the ice bin by entering the Service screen>
Service Outputs> Dispense & Blend and toggling the Ice
Motor ON until all ice has been dispensed from the ice bin.
8. Set the power rocker switch on the top right of the unit to
the OFF position and disconnect power cord from source.
9. Remove top cover from the water reservoir by pulling it up
and off.
10. Spray and wipe down the reservoir lid inside and out with
sanitizing solution.
11. Using a clean pitcher/cup fill reservoir with sanitizing solution
from the bucket. Remainder of solution will be used for
manual sanitizing of other parts.
12. Remove ice dispense motor assembly from the top of the
bin by removing six (6) thumbscrews, four (4) on the top
cross member and two (2) that secure it to the bin lid.
13. Loosen the two (2) floating nuts on the clear ice chute
cover and remove the clear ice chute cover.
14. Using a clean pitcher/cup pour the sanitizer solution into
the top of the evaporator unit full, any excess will exit
through the overflow tube in the reservoir.
NOTE: Once the evaporator is full fill the pitcher/cups on more
time and set aside for later use.
