Chapter 1 – Introduction and Product Description
Multi-Tech Systems, Inc. SMSFinder User Guide for System Administrators (Document S000451B) 11
Technical Specifications
Specifications Description
Hardware Interface
Network: 10/100BaseT
Connector: RJ-45 Ethernet connection
Ports
LAN: 1 Port
Wireless Modem Frequencies
Quad-band GSM 850/900/1800/1900 MHz
Dimensions
6.4" w x 1.2" h x 6" d
(16.3 cm x 3.0 cm x 15.2 cm)
Weight
1.25 lbs.
(.56 kg)
Operating Temperature
+32
o
to +120
o
F (0
o
to +50
o
C)
Note: UL listed @ +40
o
C (limited by the power supply)
Humidity
25–85% non-condensing
Hardware Connectors
SIM connector: Standard 3V
Antenna: RF antenna 50 ohm SMA (female)
See Appendix B for antenna specifications
Power External Power Supply
Input: 100 ~240V, 0.5A 50-60- Hz
Output: 9VDC, 1.7A
Power Consumption
Maximum power consumption is 0.95A at 9V
Certifications and Approvals CE Mark & R&TTE
EMC:
FCC 2, 15, 22, 24
EN 55022
EN 55024
Safety:
cUL
UL 60950
EN 60950
Network:
PTCRB
Warranty
2 years
Features
Sends SMS messages to one or multiple individuals, a group, or
multiple groups
Supports up to 20,000 entries in the address book
Supports sorting and searching the address book
Allows importing address books (standard CSV file format)
Allows setup of up to 50 pre-configured SMS messages
Broadcast pre-defined SMS based on receipt of matching SMS and/or
phone number
Setup user accounts with different rights
Integrated quad-band GSM modem
Web-based configuration and management
Flash memory to update firmware with the latest enhancements
Desktop or panel mounting
