Charging the Tool
The Tool is equipped with a lithium ion rechargeable battery. On a single charge the battery can last up to ten hours.
An indication of the battery lifetime can be seen on the Tool User Interface Screen and on the App while in operation.
When charging, the User Interface Screen displays the progress of the bars. When the battery is finished charging the
Tool will shut off. There are five indicator bars that each represent two hours of operation. When there is just one
bar left the App will show it in red. Only use the supplied chargers or those recommended by Multiwave Sensors. A
wall and car charger are included with the system.
15
Bars displayed while charging
Voltage diagnostic
Bars displayed during operation
(not charging) in Quick Measure
and Align Antenna Screen
Note: When there is only one bar
it will be displayed in red
28
