Introduction
The Smart Aligner System is a GPS-based compass designed to effectively and efficiently align antennas in real time. The
Smart Aligner Tool provides a True North or Grid North Azimuth measurement, Tilt, Roll and Position. Once the Tool is
mounted to the antenna using the Universal Mounting Bracket, the Tool is simply turned on. From there the user
interface is the full feature App on any iOS or Android smart device. Reporting is as simple as a few clicks with the report
being able to be emailed directly from the App. The Tool can be mounted in eighteen different configurations for the
most demanding spatial and RF conditions. For transport and storage the Tool folds to within 19” in length.
DOWNLOAD THE iOS Smart Aligner App from the App Store by searching for “Smart Aligner Multiwave”
DOWNLOAD the Android Smart Aligner App from Google Play by searching for “Smart Aligner Multiwave”
1
Safety
2
When transporting/carrying the Smart Aligner System up a tower follow all relevant safety procedures and requirements.
Always use the tether lines as described in this manual.
Use supplied or approved chargers (12VDC – 1.5A) to charge the battery.
Approvals
3
Declaration of Conformity
We declare that this product has been tested to and meet the requirements of:
EMC
FCC Part 15 Subpart B: 2008
EN 61326-1
ICES-003:2004
Safety
EN 61010-1
RoHS and WEEE Compliance
The European Union has legislated to enforce the RoHS and WEEE directives.
RoHS : Restriction of certain Hazardous Substances in electronic equipment.
WEEE: Waste Electrical and Electronic Equipment.
Multiwave Sensors Inc. can confirm to the best of our knowledge that the Smart Aligner System is compliant with the
above directives.
In the event that the Smart Aligner battery does not charge properly, call Multiwave Sensors Inc., and if required the
Smart Aligner System should be sent back to Multiwave Sensors Inc. for repair and proper disposal of the battery.
3
WARNING
