Section 40 00-02-0716
2013-06-03 - 24 -
PRESSURE MAX: Set this to the maximum value of the pressure transducer. For
example, if the transducer range is 0-100 PSI, enter 100. (adjustable from -500 to 5000
PSI) Factory set to 100 PSI
PRESSURE MIN: Set this to the minimum value of the pressure transducer. For
example, if the transducer range is 0-100 PSI, enter 0. (adjustable from -50
PSI) Factory set to 0.
PSI XDUCER MAX CNT: With 5 VDC or 20mA. applied to the analog channel, make the
top line read the same value as the bottom line. Factory set to 904. (If transducer is 0-5
VDC, enter 1023 in this set point)
PSI XDUCER MIN CNT: With 1 VDC or 4mA. applied to the analog channel, make the
top line read the same value as the bottom line. Factory set to 181. (If transducer is 0-5
VDC, enter 0 in this set point)
START LEVEL: When “level” is selected in the start / stop type, an auto start will occur
when the system level reaches this set point. (adjustable from 0 to 100.0 FT) Factory set
STOP LEVEL: When “level” is selected in the start / stop type, an auto stop will occur
when the system level reaches this set point. (adjustable from 0 to 100.0 FT) Factory set
MAINTAIN LEVEL: When “level” is selected in the throttle type, the engine will be
throttled between the “minimum” and “maximum” rpm set points to maintain this level.
(adjustable from 0 to 100.0 FT) Factory set to 10.0 FT.
DEADBAND LEVEL: When “level” is selected in the throttle type, no throttling will occur
while the level is in the deadband. This set point extends above and below the maintain
set point. (adjustable from 0 to 100.0 FT) Factory set to 1.0 FT.
LEVEL OFFSET: Enter in feet the distance from the bottom of the tank or sump to the
transducer. This value is added to the actual level reading. Factory set to 0.0
LEVEL TYPE: Enter type of level control required. The choices are “Empty”, “Fill” or
“Proportional”. Empty starts on high and stops on low. Fill starts on low and stops on
high. S57 and S58 should be set accordingly. Proportional throttling is dedicated to
EMPTY. The engine is throttled to the maximum rpm setpoint if the level is at or above
the start level. As the level drops, the engine will be throttled down proportionally. When
the level drops to the stop setpoint, the engine will be at the minimum rpm setpoint, and
an auto stop will occur. Factory set to Empty.
NOTE: This setpoint does not apply to FLOATS.
HIGH LEVEL: A self-clearing alarm will occur if the level reaches this setpoint. Factory
set to 20.0 FT.
LOW LEVEL: A self-clearing alarm will occur if the level reaches this setpoint. Factory
set to 1.0 FT.
LEVEL MAX: Set this to the maximum value of the level transducer. For example, if the
transducer range is 0-10.0 FT, enter 10.0. (adjustable from 0 to 100 FT) Factory set to
LEVEL MIN: Set this to the minimum value of the level transducer. For example, if the
transducer range is 0-10.0 FT, enter 0. (adjustable from 0 to 100 FT) Factory set to 0.
