Murphy EMS PRO User Manual

Section 40 00-02-0716
2013-06-03 - 36 -
Registers
Registers are adjustable or varying data locations within the controller whose value is an integer value
not just ON or OFF. They can represent the system analog input for flow or pressure. The registers
could be an adjustable system parameter such as delay on start. The following is a list of the registers
that can be accessed. The maximum number of registers that can be read at one time is 125. The
starting address of the registers is 40001.
NOTE: If a query is made to the EMS PRO controller beyond the published amount of
registers, the EMS PRO controller will ignore the message as an invalid query.
REGISTER
#
TYPE DESCRIPTION
40001
Read Only
Running Hours, upper byte.
40002
Read Only
Running hours, lower byte.
40003
Read Only
Engine RPM
40004
Read Only
Battery Voltage. (12.5 will read 125)
40005
Read Only
Oil Pressure.
40006
Read Only
Engine Temperature.
40007
Read Only
System Status: The following is a description of the bits:
Bit 0
(LSB) Auto Ready: (1) yes, (0) no.
Bit 1
Prestart Timing: (1) yes, (0) no.
Bit 2
Start Delay Timing: (1) yes, (0) no.
Bit 3
Warm-up Delay Timing: (1) yes, (0) no.
Bit 4
Fill Mode: (1) yes, (0) no.
Bit 5
At Load: (1) yes, (0) no.
Bit 6
Stop Delay Timing: (1) yes, (0) no.
Bit 7
Cooldown Delay Timing: (1) yes, (0) no.
Bit 8
Common Failure: (1) yes, (0) no.
Bit 9
Spare.
Bit 10
Spare.
Bit 11
Spare.
Bit 12
Spare.
Bit 13
Spare.
Bit 14
Spare.
Bit 15
(MSB) Spare.
40008
Read Only
Shutdown Status: The following is a description of the bits:
Bit 0
(LSB) Low Oil Pressure: (1) yes, (0) no.
Bit 1
High Engine Temperature: (1) yes, (0) no.
Bit 2
Low Coolant Level: (1) yes, (0) no.
Bit 3
High Low Oil Level: (1) yes, (0) no.
Bit 4
Loss of Speed: (1) yes, (0) no.
Bit 5
No Speed Signal: (1) yes, (0) no.
