Description
User manual 55530_hdb_en_16 20 / 156
3.2.6 Shared Device
Shared Device is a PROFINET IO function which enables access to an IO de-
vice from two IO controllers. A special advantage is the use of Shared Device
in systems with standard and failsafe control units.
The module gives the second standard IO controller read access to the input
and output data. This data is summarized in a subslot.
Fig. 3-6: Module in Shared Device
For further information, refer to chap. 8.9 "Shared Device configuration"
