Configuration/settings
User manual 55530_hdb_en_16 112 / 156
8.7 Media redundancy (MRP) configuration
MRP The procedure regarding the configuration of media redundancy is described
in the engineering software manual.
In this document, a configuration example is described using the Siemens TIA
Portal engineering software.
Preparatory steps:
1 | Set up a project in the TIA portal.
2 | Add a controller and a PROFINET Managed Switch.
3 | Add the MVK-MPNIO module.
4 | Assign the MVK-MPNIO module to the controller
(see Fig. 8-41: "Setting up the MPR manager").
