6.1.1 Sensors and actuators
Connecting the
M12 ports
Fig. 6-1: Example of M12 connection inputs and outputs
NOTE
Feeding in an external mass via M12 female connectors can lead to faults.
 Do not feed external mass to the module via M12 female connectors.
You will find a wide range of connecting wires in the catalog or in the online
shop of Murrelektronik GmbH at: http://shop.murrelektronik.com
M12 0,6 Nm
Art.-No.
7000-99102-0000000
