Cube67 System Manual
17 V 2.5
Art. No.
Designation
56 656 01
DO24 E Valve MPA
56 656 02
DO32 E Valve HF03
56 656 03
DO32 E Valve VM10
56 656 04
DO23 E Valve SMC
56 656 05
DO22 E Valve CPA
56 656 06
DO24 E Valve HF04
56 656 07
DO24 E Valve SMC M27
56 656 09
DO32 E Valve MAC
56 656 10
DO32 E Valve Vesta
56 656 11
DO22 E Valve Vesta
56 665 00
DIO8 E Cable M12 ID
56 600 0
DIO8 E Cable M12 ID 1,2m
3.1.11 Internal System Connection Hybrid Line
The green system line is a shielded hybrid line for
- communication between bus node and I/O modules.
- transfer of sensor supply.
1
- transfer of actuator power supply.
Use only our preterminated lines for the internal system connection.
Table 3-7 : Internal system connections
Length
Art. No.
straight-straight
90°-90°
0.3 m
7000-46041-8020030
7000-46061-8020030
0.6 m
7000-46041-8020060
7000-46061-8020060
1.0 m
7000-46041-8020100
7000-46061-8020100
1.5 m
7000-46041-8020150
7000-46061-8020150
2.0 m
7000-46041-8020200
7000-46061-8020200
2.5 m
7000-46041-8020250
7000-46061-8020250
3.0 m
7000-46041-8020300
7000-46061-8020300
3.5 m
7000-46041-8020350
7000-46061-8020350
4.0 m
7000-46041-8020400
7000-46061-8020400
4.5 m
7000-46041-8020450
7000-46061-8020450
5.0 m
7000-46041-8020500
7000-46061-8020500
5.5 m
7000-46041-8020550
7000-46061-8020550
6.0 m
7000-46041-8020600
7000-46061-8020600
6.5 m
7000-46041-8020650
7000-46061-8020650
7.0 m
7000-46041-8020700
7000-46061-8020700
7.5 m
7000-46041-8020750
7000-46061-8020750
1
The supply voltage of Cube67 I/O modules is drawn from the sensor power supply.
