Cube67 System Manual
27 V 2.5
3.4.2 Supply of External Modules (Art. No. 56 710 / 56 720)
Analog output modules Art. Nos. 56 710 and 56 720 can be supplied via Pin 1 of the M12 socket
3
3.4.3 Analog Setting Modules
by the
actuator power supply (not switchable). When measuring the total current of 4 A for the whole branch, the
maximum current draw per slot is 1.6 A.
They can be connected to analog output modules Cube67 AO4 C 4xM12 (U)/(I).
The power for analog output variables of Cube67 modules Art. Nos. 56 710 / 56 720 is drawn from the
sensor power supply. The output value is not dependent on the actuator power supply status.
The output value of Cube67 AO4 C 4xM12 (U)/(I) modules is not
dependent on the
actuator power supply status.
3.4.4 Actuators
The maximum current drawable from the outputs can be found in the Technical Data (User Manual Art.
No. 56 971).
Please observe the maximum current-carrying capacity of the power supply on the bus node or other
power supplies. With a 7/8“ power connector, the maximum total current for the actuator supply is 9 A.
CAUTION:
When extending the actuator supply via the internal system connection, take care to
ensure that the total current of all modules in the segment does not exceed
4 A.
CAUTION:
The total current of all actuators supplied via the bus node or a power distributor in a
Cube67 system may not exceed 9 A.
CAUTION:
Reverse polarity of the actuator power may damage the module!
3
Not for Art. No. 56 710 / 56 720 / 56 740.
4
The assignments of the M12 socket for the module Cube67 AO4 C 4xM12 (U)/(I) are described in
Technical Data, User Manual Art. No. 56 971.
