Maintenance Manual – SC Cutting Plotter
116 AP-74030, Rev / B
Ref. Description Partnumber Qty
# Pressure roller assy MY-10402 1
1 Pressure base ME-10402 1
2 Pressure arm ME-10095 1
3 Pressure roller DE-44190 1
4 Spring shaft ME-20611 1
5 Spring ME-20611 1
6 Pivot shaft ME-20613 1
7 Roller shaft ME-20614 1
8 Connection shaft ME-20612 1
9 Hex nut M8 BM-9104-108004 2
10 Washer BR-14338 2
11 E-ring 3.2 BR-31032 4
12 E-ring 2.3 BR-31023 2
13 Plastic washer DE-44192 2
- ---------------------------------------------------------- --------------------------- -
14 UP/DOWN cam ME-10403 1
15 Cam bracket ME-20647 1
16 Screw M3x4 DR-4001-43993 1
