Maintenance Manual – SC Cutting Plotter
78 AP-74030, Rev / B
8.3. Cover left assy.
Ref. Description Partnumber Qty
1 Cover left SC-650 ZME-20655 1
1 Cover left SC-750 ZME-20755 1
1 Cover left SC-1000 ZME-21005 1
1 Cover left SC-1300 ZME-21305 1
2 Screw M3x8 DR-4001-43329 3
3 Screw 3.0x10 BM-2301-503010 6
4 Label SC-650 LB-20650 1
4 Label SC-750 LB-20750 1
4 Label SC-1000 LB-20100 1
4 Label SC-1300 LB-20125 1
