MUTOH SC-550 - Cutting Head Errors; Other Errors

Maintenance Manual – SC Cutting Plotter
25 AP-74030, Rev / B
4.2.3. Cutting head errors.
ERROR CODE
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
POSITION
Timeout MC
X X X
OVER CURRENT
Moving Coil
X X X X
A/D failure
Moving Coil
X X X X
4.2.4. Other errors.
ERROR CODE
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
ILLEGAL Mainboard rev. X X X X X
ILLEGAL Mainboard TYPE X X X
