Maintenance Manual – SC Cutting Plotter
47 AP-74030, Rev / B
6. PARTS REPLACEMENT AND ADJUSTMENT.
6.1. Maintenance access table for parts replacement.
Removal of the following cover gives access to the following part or mechanical adjustment :
COVER
Gives access to
Transparent
Cover
(Not on SC-550)
Cutting head
Auto sheet-off system (Not on SC-550)
Pressure rollers
Cutting mat
Left cover Y-axis return pulley assy
Y-axis drive belt tension adjustment
Power supply board (SC-550 only)
Right cover Y-motor
Y-drive pulley assy
Y-drive belt (short) tension adjustment
Pressure roller UP/DOWN sensor
Pressure roller UP/DOWN mechanism
Keyboard assy
X-drive belt
Main/driver board (SC-550 only)
EPROM set (SC-550 only)
EEPROM (SC-550 only)
Terminal board (SC-550 only)
Y-rail cover Pressure roller assy
Acrylic cover switch (Not on SC-550)
Y-rail assy
Penhead flex cable assy
Pressure roller pressure adjustment
PCB-box
(Not on SC-550)
X-motor cover
(SC-550 only)
Main/driver board assy
EPROM set
EEPROM
Power supply board assy
Terminal board assy
X-motor assy
X-drive belt tension adjustment
Fan motor
Grid cover Grid rollers
Paper sensors
