MUTOH SC-550 - 7 Jig Tool List; Special Glue

Maintenance Manual – SC Cutting Plotter
73 AP-74030, Rev / B
7. JIG TOOL LIST.
7.1. Jig tool list.
PART NAME PART#
Adjustment Pen 10 g JD-41440
Bar tension gauge 50 g JD-41446A
Bar tension gauge 500 g
JD-41446B
Bar tension gauge 5 kg JD-41446C
Pressure measurement attachment JD41563
Steel belt tension attachment JD-41565
L shaped Allen key 1.27 mm (1/20”)
+ Screw driver (Philips) #1
+ Screw driver (Philips) #2
- Screw driver
Open wrench 13 mm
Box wrench 13 mm
7.2. Special glue.
External screw locking glue : LOCTITE 7400 (VERNISTOP)
Screw thread locking glue : LOCTITE 243
Glue for fixing Y)motor pulley
: LOCTITE 406
