154 3.6 Print quality adjustment
3.6.2 Custom print quality adjustment
Perform adjustment for all patterns (A to F).
All print modes will be adjusted.
This menu consists of the following menus.
Follow the procedure below to perform adjustment.
1. Print out the confirmation pattern and check the degree of misalignment.
3.6.2.1 Custom confirmation pattern
2. Perform rough adjustment when the degree of misalignment is big.
3.6.2.2.1 Rough Pattern ALL
Perform micro adjustment when the degree of misalignment is small.
3.6.2.3 Custom micro adjustment pattern
NOTE
• Perform rough adjustment first when the degree of misalignment is difficult to determine.
• Perform adjustment for A to F patterns if they are misaligned.
3. Print out the confirmation pattern again and check if the printer has been adjusted properly.
3.6.2.1 Custom confirmation pattern
4. If it has not been adjusted yet, return to Step 2.
Menu name Description Reference
Custom confirmation pattern Print out the confirmation patterns (A to
F) and check the degree of misalignment.
3.6.2.1 Custom confirmation
pattern
Custom rough
adjustment
pattern
Rough
PatternALL
Perform this when the degree of
misalignment is big. All confirmation
patterns (A to F) will be adjusted.
3.6.2.2.1 Rough Pattern ALL
Individual Rough
Adj. pattern
Perform this when the degree of
misalignment is big. One of the
confirmation patterns (A to F) will be
adjusted.
3.6.2.2.2 Rough Pattern A to F
Custom micro
adjustment
pattern
Adj. PatternALL Perform this when the degree of
misalignment is small. All confirmation
patterns (A to F) will be adjusted.
3.6.2.3.1 Fine Pattern ALL
Individual Adj.
pattern
Perform this when the degree of
misalignment is small. One of the
confirmation patterns (A to F) will be
adjusted.
3.6.2.3.2 Fine Pattern A to F
