NAD T 752 - EXPLODED VIEW PARTS LIST

48
Item Part No. Description Qty.
51 14-0401002-04-00 SCREW M4 X 10 BLK-PLT 4
52 15-0400320-07-20 NUT M4 X 3.2 4
53 15-0900220-11-30 NUT M9 X 2.2 1
54 16-0320560-09-20 SPRING WASHER 18
55 16-0350080-04-35 STEEL WASHER 4
56 16-0400074-10-31 SPRING WASHER 4
57 16-0400100-08-25 STEEL WASHER 4
58 17-0500960-00-01 PCB SUPPOT H=9.6MM 3
59 17-1402600-30-22 RUBBER FOOT 4
60
25-0220054-30-18 POWER TRANSFORMER EI-114 115/230V 1
61*C
29-4000002-00-38 AM/FM TUNER MODULE KST-MB114MA-1-20 1
61*AH
29-4000003-00-38 AM/FM TUNER MODULE KST-MB114MA-1-22 2
62 34-0061030-00-60 JUMPER PLUG 3
63*C
34-0100002-00-78 AC OUTLET (C) 1
64*AH
34-0101001-00-70 AC OUTLET (AH) 1
65*AH
36-2061010-07-94 POWER CORD UL/CSA SPT-2 AWG 18X2 1
66*C
36-2283110-07-96 POWER CORD EURO-PLUG 10A/250V 1
67 37-2011225-00-63 FAN 1
68 38-1001500-00-65 SILICONE RUBBER 7
69 38-1030100-00-65 MICA 1.5KV 22 X 27 X 0.125MM 10
70
34-0100002-00-70 AC INLET IEC 2 PIN 10A/250V 1
71
35-0101109-00-67 POWER SW TV-8 10A 250V 1
NOTE:
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR RISK OF FIRE AND
ELECTRICAL SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
<*AH > : USA, CANADIAN MODEL ONLY.
<*C > : EUROPEAN MODEL ONLY.
