NAD T 752 - FRONT;CENTER;SURROUND;DSP BOARD COMPONENTS; AUDIO BOARD COMPONENTS; COMPONENT VIDEO BOARD COMPONENTS

49
ELECTRICAL PARTS LIST
FRONT AND CENTER AMPLIFIER BOARD
PCB ASSEMBLY 80-0907520-40-00 FRONT AND CENTER AMP ASSEMBLY
SURROUND AMPLIFIER BOARD
PCB ASSEMBLY 80-0907520-18-00 SURROUND AMP ASSEMBLY
DSP BOARD
PCB ASSEMBLY 80-0907520-65-00 DSP ASSEMBLY
AUDIO BOARD
TRANSISTORS
Q301,Q303,Q307,Q309 21-0000120-70-14 XTR NPN HFE 68 30MHz SPT
DTC144ES
Q302,Q308 21-0000450-70-14 XTR PNP 68 250MHz SPT DTA144ESA
CAPACITORS
C317-C332 22-3226052-00-43 CAP ELEC SS 2.2uF 50V 20%
C333-C334 22-3470022-00-43 CAP ELEC SS 47uF 16V 20%
ICS
U301 27-7892730-24-11 I.C. ANALOG SW SMD TC9273F-004
U302,U303 27-9496600-21-02 I.C. QUAD BILATERAL SWITCH LC4966
U304 27-7055320-18-14 I.C. AUDIO LOW NOISE OP-AMP SMD
NJM5532M
RCA JACKS
M303 34-4040420-00-60 RCA JACK 4 R-R/W-W GOLD
RS-453G-04
M301-M302 34-4060420-00-60 RCA JACK 6 R-R-R/W-W-W GOLD
RCA-653D-04
COMPONENT VIDEO BOARD
TRANSISTOR
Q4301 21-0000120-70-14 XTR NPN HFE 68 30MHz SPT
DTC144ES
CAPACITORS
C4301-C4306 22-3226052-00-43 CAP ELEC SS 2.2uF 50V 20%
C4310-C4312,C4325 22-3100022-00-43 CAP ELEC SS 10uF 16V 20%
C4313-C4315 22-3106052-00-43 CAP ELEC SS 1uF 50V 20%
C4316,C4318,C4320 22-3101022-00-43 CAP ELEC SS 100uF 16V 20%
C4317,C4319,C4321 22-3220022-00-43 CAP ELEC GS 22uF 16V 20%
ICS
U4301 27-5176600-18-23 I.C. VIDEO 3-CH 75 OHM DRIVER
BA7660FS
U4302-U4303 27-0140520-18-00 I.C. SINGLE DUAL TRIPLE
M74HC4052MIR
Reference No. Part No. Description
