NAD T 752 - DIGITAL BOARD COMPONENTS; KEYBOARD COMPONENTS

50
Reference No. Part No. Description
RCS JACKS
M431-M432,M434 34-4032020-00-60 RCA 3 G-BL-R GOLD RS-354G-18
SWITCH
S4301 35-4102209-00-67 SW SLIDE 2P2T JSK022N09-G09
DIGITAL BOARD
FIBRE OPTICAL
J1008 26-6691386-00-16 FIBRE OPTIC TRANSMITTER
GP1FA550TZ
J1005-J1006 26-6701380-01-16 FIBRE OPTIC RECEIVING UNIT
GP1FA550RZ
CAPACITORS
C1066, C1067 22-3226052-00-43 CAP ELEC SS 2.2uF 50V 20%
IC
U1024, U1026 27-0804990-18-00 I.C. HEX INVERTER M74HCU04MIR
RCA JACKS
J1001-J1004,J1007 34-4010320-00-60 RCA JACK 1 BLACK GOLD RS-146G/B
KEYBOARD
DIODES
D212,D214-D218 20-0000000-00-13 DIODE SW 4NS DO35 IN4148
D213 20-3262902-00-01 DIODE ZENER BZX55 6.2V 1/2W 5%
D219 20-1001401-20-44 DIODE RECT 1A/400V D041 1N4004
D220 20-3251902-00-01 DIODE ZENER BZX55 5.1V 1/2W 5%
TRANSISTORS
Q202-Q206 21-0000010-00-46 XTR NPN HEF 100 200MHz C1815Y
CAPACITORS
C203-C206 45-0100054-52-57 CAP CER SMD 10pF 50V 5%
C207,C214 22-3100022-00-43 CAP ELEC SS 10uF 16V 20%
C208-C211 22-3470022-00-43 CAP ELEC SS 47uF 16V 20%
C212 22-3102012-00-28 CAP ELEC GR 1000uF 10V 20%
C201, C202, C213, C215-C220 45-0104056-57-57 CAP CER SMD 0.1uF 50V 20%
C222, C241, C242 45-0102055-55-57 CAP CER SMD 1nF 50V 10%
C223 45-023055-55-57 CAP CER SMD 1nF 50V 10%
IR
D201 26-0941380-00-00 IR RX 940nm 37.9KHz SHIELD ST
FM-7138TE5
ICS
U201(A/V-R)-U202(VFD) 27-1086400-04-87 I.C. MCU 8 BIT 64KROM 512 BYTE
M6759 (sold as a pair)
U203 27-9630600-14-62 I.C. VFD DRIVER PT6306
U204-U207 27-0540940-18-00 I.C. 8-STAGE BUS REGISTER
HCF4094BM1
