47
EXPLODED VIEW PARTS LIST
Item Part No. Description Qty.
110-0752001-00-10WINDOW LENS 1
210-0752002-71-00VOLUME KNOB ASSEMBLY 1
310-0752005-71-00VOLUME BEZEL 1
410-0752007-01-00VIDEO COVER 1
510-0752011-00-00LED LENS 1
610-0752012-01-00RACKER BUTTON 2
710-0752015-01-00LED BEZEL 1
810-0752017-01-00PLASTIC FOOT 4
910-0752022-01-00POWER BUTTON 1
10 10-0752025-01-00 RACKER BEZEL 2
11 10-0752032-01-00 INPUT BUTTON 3
12 10-0752035-71-00 INPUT BUTTON LOZENGE 1
13 10-0752042-01-00 DUO BUTTON 2
14 10-0752045-01-00 POWER BUTTON BEZEL 1
15 10-0752055-01-00 DUO BEZEL 2
16 10-0752065-01-00 VIDEO HOUSING 1
17 10-0752075-01-00 DISPLAY BRACKET 1
18 11-0570065-20-00 HEX SPACER 10
19 11-0570075-80-00 L BRACKET 2
20 11-0752000-95-10 FASCIA 1
21 11-0752003-85-10 TOP COVER 1
22 11-0752004-80-00 BOTTOM CHASSIS 1
23*C 11-0752006-94-10 REAR PANEL (C) 1
24*AH 11-0752006-94-10 REAR PANEL (AH) 1
25 11-0752008-80-00 EXTRUDED HEATSINK L 1
26 11-0752018-80-00 EXTRUDED HEATSINK R 1
27 11-0752025-80-00 SUBFASCIA 1
28 11-0752028-95-00 SIDE CAP L 1
29 11-0752035-80-00 FAN MOUNTING BRACKET 1
30 11-0752038-95-00 SIDE CAP R 1
31 11-0752045-80-00 HEATSINK MOUNTING BRACKET 4
32 11-0752055-80-00 SIDE MOUNTING BRACKET 2
33 11-0752065-80-00 PHONE BRACKET 1
34 11-0752075-80-00 DUMMY BRACKET 2
35 11-1500005-80-00 U-BRACKET 4
36 11-2100135-80-00 CLIP THERMAL SWITCH 1
37 13-0260500-02-00 SCREW 2.6 X 5 NI-PLT 2
38 13-0260600-02-00 SCREW 2.6 X 6 NI-PLT 6
39 13-0260803-02-00 SCREW 2.6 X 8 NI-PLT 14
40 13-0300803-04-00 SCREW 3.0 X 8 NI-PLT 2
41 14-0300600-02-00 SCREW M3 X 6 NI-PLT 21
42 14-0300600-04-00 SCREW M3 X 6 BLK-PLT 2
43 14-0300600-52-00 SCREW 3.0 X 6 NI-PLT 10
44 14-0300800-53-00 SCREW 3.0 X 8 ZINC-PLT 47
45*C 14-0300800-54-00 SCREW 3.0 X 8 BLK-PLT 54
45*AH 14-0300800-54-00 SCREW 3.0 X 8 BLK-PLT 52
46 14-0301000-54-00 SCREW 3.0 X 10 BLK-PLT 3
47 14-0301003-04-00 SCREW M3 X 10 BLK-PLT 4
48 14-0301203-02-00 SCREW M3 X 12 NI-PLT 18
49 14-0400802-04-00 SCREW M4 X 8 BLK-PLT 6
50 14-0400803-44-00 SCREW 4.0 X 8 BLK-PLT 2
To Next Page
