NAD T 752 - MAIN BOARD COMPONENTS

51
Reference No. Part No. Description
U208 27-0140510-18-00 I.C. MUX/DEMUX M74HC4051MIR
U209 27-0324591-18-00 IC OCTAL BUS TRANSCEIVER
74VHC245M
U210 27-2300225-00-00 I.C. EEPROM 2K BYTE 250nS
M24C16-BN6
CRYSTAL
X201-X202 28-5221200-06-19 CRYSTAL 22.1184MHZ 30ppm HC-49S
IC SOCKET
U201A 34-6244000-00-79 IC SOCKET PLCC 44 FT
TACT SWITCHES
S201-S217 35-1001117-00-67 SW TACT 1PIT 50mA/12V TM114BFJ
ENCODER
M201 35-6001219-00-08 ENCODER ROTATRY L=20mm W/O
CLICK ECB16
VFD
VFD 41-4340100-00-13 VFD 16-BT-93GNK
RESISTORS
R201-R207, R212, R213, R215, R219, 44-0100220-51-00 RES SMD 10K OHM 5%
R223-R224, R226-R227, R229, R231-R232
R209-R210 44-0100520-51-00 RES SMD 10M OHM 5%
R233 44-0470220-51-00 RES SMD 47K OHM 5%
R216 44-0390020-51-00 RES SMD 390 OHM 5%
R217-R218 44-0150120-51-00 RES SMD 1.5K OHM 5%
R220, R236, R237 44-0470120-51-00 RES SMD 4.7K OHM 5%
R221, R230 44-0220120-51-00 RES SMD 2.2K OHM 5%
R222 44-0220020-51-00 RES SMD 220 OHM 5%
R238 44-0120220-51-00 RES SMD 12K OHM 5%
R241, R242 44-0100020-51-00 RES SMD 100 OHM 5%
LED BOARD
LED
D211 26-0012305-01-17 LED RED-GREEN 3RGSW-1-A
MAIN BOARD
DIODES
D701-D710,D713 20-1001401-20-44 DIODE RECT 1A/400V D041 1N4004
D711 20-3227002-00-47 DIODE ZENER BZX55 27V 1/2W 5%
D712,D714 20-0000000-00-13 DIODE SW 4NS DO35 IN4148
D715 20-5004700-50-02 DIODE BRI 4A/70V RS402L
D716-D717 20-3951943-50-01 DIODE ZENER ZY5.1 2W 10%
TRANSISTOR
Q701 21-0000140-00-11 XTR NPN HFE 120 100MHz SS8050C
