NAD T 752 - Page 54

52
Reference No. Part No. Description
CAPACITORS
C701,C705-C706,C716 22-3102032-00-28 CAP ELEC GR 1000uF 25V 20%
C702,C719,C723 22-3101022-00-43 CAP ELEC SS 100uF 16V 20%
C704 22-3332032-00-28 CAP ELEC GR 3300uF 25V 20%
C707,C721,C724 22-3222032-00-34 CAP ELEC GS 2200uF 25V 20%
C710 22-3470052-00-43 CAP ELEC SS 47uF 50V 20%
C711-C713 22-3102052-00-28 CAP ELEC GR 1000uF 50V 20%
REGULATORS
U701,U704-U706 27-3000501-17-14 I.C. VOLT REG 5V 1A NJM7805FA
U702 27-3001201-17-14 I.C. VOLT REG 12V 1A NJM7812
U703 27-3101201-13-14 I.C. VOLT REG F NJM7912
MULTI-CHANNEL BOARD
DIODE
D601 20-0000000-00-13 DIODE SW 4NS DO35 IN4148
TRANSISTORS
Q601-Q602 21-0000360-00-00 XTR NPN HFE200-700 30MHz
2SC2878A
Q603 21-0100390-70-14 XTR PNP HFE 30 250MHz SPT
DTA 114ESA
Q604 21-0000400-70-14 XTR NPN HFE30 250MHz SPT
DTC114ESA
Q626,Q628 21-0000120-70-14 XTR NPN HFE 68 30MHz SPT
DTC144ES
Q627 21-0000450-70-14 XTR PNP 68 250MHz SPT DTA144ESA
CAPACITORS
C607,C611-C612, C619-C622 22-3220022-00-43 CAP ELEC GS 22uF 16V 20%
C623,C681-C683
C626 22-3221022-00-43 CAP ELEC SS 220uF 16V 20%
C677-C690 22-3470022-00-43 CAP ELEC SS 47uF 16V 20%
RESISTORS
J601-J603 44-0000027-11-00 RES SMD 0 OHM 5%
ICS
U601 27-7891640-21-11 I.C. ANALOG FUNCTION SW TC9164AN
U604 27-9496600-21-02 I.C. QUAD BILATERAL SW LC4966
U605-U608 27-7055320-18-14 I.C. LOW NOISE OP-AMP NJM5532M
RCA JACKS
M601 34-4060420-00-60 RCA JACK 6 R-R-R/W-W-W GOLD
RCA-653D-04
M602 34-4020320-00-60 RCA JACK 2 B/B GOLD RS-253G-02
M603 34-4040420-00-60 RCA JACK 4 R-R/W-W GOLD
RS-453G-04
