NAD T 752 - PRE-OUT BOARD COMPONENTS

53
Reference No. Part No. Description
PRE-OUT BOARD
DIODES
D602,D604 20-3275902-00-01 DIODE ZENER BZX55 7.5V 1/2W 5%
D605-D609, D611-D615 20-0000000-00-13 DIODE SW 4NS DO35 IN4148
TRANSISTORS
Q605 21-0000140-00-11 XTR NPN HFE 120 100MHz SS8050C
Q607 21-0100131-00-11 XTR PNP HFE 170 1.5A SS8550C
Q608-Q615 21-0000350-70-00 XTR NPN HFE200-700 30MHz SPT
RN1241A
Q616,Q618,Q620,Q622,Q624 21-0100390-70-14 XTR PNP HFE 30 250MHz SPT
DTA 114ESA
Q617,Q619,Q621,Q623,Q625 21-0000400-70-14 XTR NPN HFE30 250MHz SPT
DTC114ESA
CAPACITORS
C613-C618, C624-C625, C635-C636 22-3336052-00-43 CAP ELEC SS 3.3uF 50V 20%
C627-C628, C633-C634 22-3101022-00-43 CAP ELEC SS 100uF 16V 20%
C679-C680, C691-C692 22-3470022-00-43 CAP ELEC SS 47uF 16V 20%
C637, C642, C647, C652, C657, C662, 22-3100022-00-43 CAP ELEC SS 10uF 16V 20%
C667,C672
C640, C645, C650,C655, C660, C665, 22-3220022-00-43 CAP ELEC GS 22uF 16V 20%
C670, C675
C684-C688 22-3331022-00-28 CAP ELEC GR 330uF 16V 20%
C693-C694 22-4182203-10-10 CAP MYLAR KT-G 8.2nF 100V 10%
C695-C696 22-4115303-10-28 CAP MYLAR MCC-R 15nF 100V 10%
C697-C698 22-4233402-00-31 CAP MPF 0.33uF 63V 5%
RESISTORS
J6101-J6104 44-0000027-11-00 RES SMD 0 OHM 5%
INDUCTOR
L601 24-0101108-00-28 IND CHOKE 100uH 10%
ICS
U602-U603 27-7262446-10-01 I.C. VOL/TONE CONTROL
M62446FP
U609-U612 27-7055320-18-14 I.C. LOW NOISE OP-AMP NJM5532M
RCA JACKS
M607 34-4040500-00-60 RCA JACK 4 R-W/R-W GOLD
RS-413G-08
M608,M610 34-4020300-00-60 RCA JACK 2 B/B GOLD RS-213G-02
M609 34-4040400-00-60 RCA JACK 4 R-R/W-W GOLD
RS-413G-04
POWER SUPPLY BOARD
CAPACITORS
C763
2-1103470-35-45 CAP CER ECKDRS 10nF 400VAC
+80/-20%
