Direct Address Program Mode
Table 4 (cont'd)
EVENT ID CODES
DATA ENTRIES OPTION
LEFT RIGHT
2 D Zone 38
2 E Zone 39
2 F Zone 40
3 blank (•) Zone 41
3 1 Zone 42
3 2 Zone 43
3 3 Zone 44
3 4 Zone 45
3 5 Zone 46
3 6 Zone 47
3 7 Zone 48
3 8 Zone 49
3 9 Zone 50
3 0 Zone 51
3 B Zone 52
3 C Zone 53
3 D Zone 54
3 E Zone 55
3 F Zone 56
4 blank (•) Zone 57
4 1 Zone 58
4 2 Zone 59
4 3 Zone 60
4 4 Zone 61
4 5 Zone 62
4 6 Zone 63
4 7 Zone 64
6 8 Area 1 KP Ambush
6 9 Area 1 KP Panic
6 0 Area 1 KP Fire
6 B Area 1 KP Aux
6 C Area 1 KP Tamper
6 D Area 1 Fail to Open
6 E Area 1 Fail to Close
7 blank (•) Area 2 KP Ambush
7 1 Area 2 KP Panic
7 2 Area 2 KP Fire
7 3 Area 2 KP Aux
7 4 Area 2 KP Tamper
7 5 Area 2 Fail to Open
7 6 Area 2 Fail to Close
LEFT DATA
ENTRIES
ALARM TYPE TIMEOUT TYPE
blank (•) Burglary Minutes
1 Fire Minutes
4 Day Zone Minutes
8 Burglary Seconds
9 Fire Seconds
C Day Zone Seconds
Table 5A
RELAY EVENT
ALARM TYPE OPTIONS
RIGHT DATA
ENTRIES
OPTIONS
1 Alarm
2 Restore
3 Trouble
4 Trouble Restore
5 Follow Zone
Table 5B
RELAY EVENT ACTIVATION CONDITIONS
Table 2
DATA
ENTRY
TURN OFF ON AREA
DISARM
blank (•) NONE
1 Area 1
2 Area 2
3 Area 1 & Area 2
4 Area 3
5 Area 1 & Area 3
6 Area 2 & Area 3
7 Areas 1, 2 & 3
8 Area 4
9 Area 1 & Area 4
0 Area 2 & Area 4
B Areas 1, 2 & 4
C Areas 3 & 4
D Areas 1, 3 & 4
E Areas 2, 3 & 4
F Areas 1-4
Table 4 (cont'd)
EVENT ID CODES
DATA ENTRIES OPTION
LEFT RIGHT
B 6 Wireless TX Tamper
B 7 Wireless TX Trouble (LB/Supervisory)
C 8 Area 1 Arming AWAY
C 9 Area 2 Arming AWAY
C 0 Area 3 Arming AWAY
C B Area 4 Arming AWAY
D blank (•) Keypad Fail
D 1 EZM Fail
D 2 Quickloader Device Control
D 5 General System Alarm
D 8 Area 1 General System Alarm
D 9 Area 2 General System Alarm
D 0 Area 3 General System Alarm
D B Area 4 General System Alarm
F blank (•) Relay Control Group 1
F 1 Relay Control Group 2
F 8 Entry Relay Area 1
F 9 Entry Relay Area 2
F 0 Entry Relay Area 3
F B Entry Relay Area 4
7 E Area 3 Fail to Close
7 F Area 4 KP Ambush
8 1 Area 4 KP Panic
8 2 Area 4 KP Fire
8 3 Area 4 KP Aux
8 4 Area 4 KP Tamper
8 5 Area 4 Fail to Open
8 6 Area 4 Fail to Close
0 8 Test Timer
0 B Memory Fail
0 C Low Battery
0 D AC Fail
0 E EZM Tamper
0 F Alarm Supervisory
B 5 RF Receiver Trouble (Tamper/Fail)
7 8 Area 3 KP Ambush
7 9 Area 3 KP Panic
7 0 Area 3 KP Fire
7 B Area 3 KP Aux
7 C Area 3 KP Tamper
7 D Area 3 Fail to Open
Table 1
DATA ENTRY
Left
Nibble
Right
Nibble
blank (•) blank (•) NONE
blank (•) 1 1
blank (•) 2 2
blank (•) 3 3
blank (•) 4 4
blank (•) 5 5
blank (•) 6 6
blank (•) 7 7
blank (•) 8 8
blank (•) 9 9
blank (•) 0 10
blank (•) B 11
blank (•) C 12
blank (•) D 13
blank (•) E 14
blank (•) F 15
1 blank (•) 16
RELAY #
Table 4
EVENT ID CODES
DATA ENTRIES OPTION
LEFT RIGHT
blank (•) blank (•) Area 1 Arm
blank (•) 1 Area 2 Arm
blank (•) 2 Area 3 Arm
blank (•) 3 Area 4 Arm
blank (•) 8 Zone 1
blank (•) 9 Zone 2
blank (•) 0 Zone 3
blank (•) B Zone 4
blank (•) C Zone 5
blank (•) D Zone 6
blank (•) E Zone 7
blank (•) F Zone 8
1 blank (•) Zone 9
1 1 Zone 10
1 2 Zone 11
1 3 Zone 12
1 4 Zone 13
1 5 Zone 14
1 6 Zone 15
1 7 Zone 16
1 8 Zone 17
1 9 Zone 18
1 0 Zone 19
1 B Zone 20
1 C Zone 21
1 D Zone 22
1 E Zone 23
1 F Zone 24
2 blank (•) Zone 25
2 1 Zone 26
2 2 Zone 27
2 3 Zone 28
2 4 Zone 29
2 5 Zone 30
2 6 Zone 31
2 7 Zone 32
2 8 Zone 33
2 9 Zone 34
2 0 Zone 35
2 B Zone 36
2 C Zone 37
RELAY EVENT OPTIONS
RELAY # AREA TIMEOUT EVENT ID COND.
See
Table 1 below
See
Table 2 below
(right nibble)
Enter a Time
period, in seconds
or minutes
See
Table 4 below
See
Tables 5A & 5B
below
To Next Page
