GEM-P816 Programming Instructions

Page 20
NAPCO Security Systems
R
NOTE: * See Pager Format Options to program
Leading Digits for Pager Format.
CS RECEIVER OPTIONS (ADDRESS 0460-0525)
Default for CS Receiver 1 Format depends on Easy Menu Question “RCVR FORMAT”. [Default = •(blank) •
(blank)] for CS Receivers 2 and 3 Formats.
CS RECEIVER FORMATS: Up to 3 CS Formats may be programmed.
 1. Select the desired CS Receiver Format from the table shown.
 2. Enter the corresponding digit in the address location for each CS Receiver. NOTE: Dark
shaded data value box shows option not available. Press [Enter] to save.
DATA
ENTRY
CS RECEIVER 1 FORMAT
blank (•) Ademco Slow, Silent Knight Slow
2 Radionics Fast
3 Silent Knight Fast
4 Radionics, DCI, Franklin Slow
5 Universal High Speed
B SIA
C Ademco Point ID
E Pager *
CS RECEIVER OPTIONS:
Select options for any of the three CS Receivers.
 1. Select the desired option entering the option number
(1-8) for each digit.
 2. Enter corresponding option number in address
location (right nibble).
NOTE: Dark shaded data value box shows option not avail-
able. Press [Enter] to save.
*NOTE: If both are selected, 1400Hz has priority over 2300Hz.
CS RECEIVER TELEPHONE NUMBERS: Enter telephone numbers for any of the three CS Receivers (Telco 1, 2 & 3).
 1. Enter digit only.
 2. Enter up to 20 digits from left to right. NOTE: Leave trailing boxes blank (•). Press [Enter] to save.
 3. Valid entries are: 1-9, B = *button, C = #button, D = 3 sec. pause, E = Wait for dial tone, F = Ignore location
Default for CS
Receiver 1 Tele-
phone Number
depends on Easy
Menu Question
“CENTRAL
PHONE #”.
[Default = blank (•)]
across digits 1-20
for CS Receiver
Telephone Num-
bers 2 and 3.
ADDRESS 0460
CS Receiver 1
Format
ADDRESS 0482
CS Receiver 2
Format
ADDRESS 0504
CS Receiver 3
Format
ADDRESS 0462-0481 (RIGHT DIGITS 1-20)
0462 0463 0464 0465 0466 0467 0468 0469 0470 0471 0472 0473 0474 0475 0476 0477 0478 0479 0480 0481
(Digits 1-20)
CS Receiver 1
Telephone
Number
CS Receiver 2
Telephone
Number
ADDRESS 0484-0503 (RIGHT DIGITS 1-20)
0484 0485 0486 0487 0488 0489 0490 0491 0492 0493 0494 0495 0496 0497 0498 0499 0500 0501 0502 0503
(Digits 1-20)
CS Receiver 3
Telephone
Number
ADDRESS 0506-0525 (RIGHT DIGITS 1-20)
0506 0507 0508 0509 0510 0511 0512 0513 0514 0515 0516 0517 0518 0519 0520 0521 0522 0523 0524 0525
(Digits 1-20)
0461
CS Receiver Options - Telco 1
0483
Default
Option
Default
Option
OFF
1
1400Hz Handshake/Kissoff *
OFF
1
1400Hz Handshake/Kissoff *
OFF
2
2300Hz Handshake/Kissoff *
OFF
2
2300Hz Handshake/Kissoff *
OFF
3
Enable Zone Number on Pulse Alarm
OFF
3
Enable Zone Number on Pulse Alarm
OFF
4
Single Digit Only
OFF
4
Single Digit Only
OFF
5
Sum Check OFF
5
Sum Check
OFF
6
3/1 with Extended Restores OFF
6
3/1 with Extended Restores
OFF
7
Enable TCP/IP AES RPT OFF
7
Enable TCP/IP AES RPT
OFF
8
RESERVED OFF
8
RESERVED
CS Receiver Options - Telco 2
0505
Default
Option
OFF
1
1400Hz Handshake/Kissoff *
OFF
2
2300Hz Handshake/Kissoff *
OFF
3
Enable Zone Number on Pulse Alarm
OFF
4
Single Digit Only
OFF
5
Sum Check
OFF
6
3/1 with Extended Restores
OFF
7
Enable TCP/IP AES RPT
OFF
8
RESERVED
CS Receiver Options - Telco 3
