RF RECEIVER & SUPERVISORY TIMER OPTIONS (ADDRESS 2029-2044 & 2056)
RF RECEIVERS: Up to 2 RF Receivers may be pro-
grammed.
1. Select the number of receivers from the table
shown.
2. Enter number in address location shown.
3. Press U to save.
RF SUPERVISORY TIMERS: RF Supervisory Timers may be programmed for each type of trans-
mitter used. A transmitter will send a transmission every time it is tripped, when there is NO activity,
the transmitter sends a status transmission about once an hour. If the receiver does NOT receive
ANY signal (a trip or a status) from a transmitter in the time specified for transmitter type, a system
trouble “WIRELESS TROUBLE/E04-NN SERVICE” will be displayed at the keypad.
1. Select timer delay from the table shown. Timers are programmed in increments of 30 minutes
each. Valid entries are [3] through [F] (90 minutes-450 minutes).
2. Enter in corresponding address locations below (right nibble).
3. Press U to save.
NOTE: These timers apply only to Supervised RF Transmitters (see RF Transmitters in Easy Menu Driven Mode Programming).
DATA ENTRIES
blank (•) None
1 1
2 2
RF RECEIVER(S)
Default for Number of Receivers
depends on Easy Menu Question for
RF Transmitters.
ADDRESS 2056
LEFT DIGIT
Number of RF
Receivers
RIGHT DIGIT
blank (•)
[Default = blank (•) from address 2029-2044]. Default = 8 (240 minutes)
RF SUPERVISORY
TIMER
RF TRANSMITTER
RF SUPERVISORY DELAY
TIME (Select timer delay
from the table at right)
Type 0 Window/Door, 2 Pt. 2029
Type 1 Window/Door, 2 Pt.
2030
Type 2 Window/Door, 2 Pt.
2031
Type 3 Window/Door, 2 Pt.
2032
Type 4 RESERVED
Type 5 PIR
2034
Type 6 PIR
2035
Type 7 Smoke Detector
2036
Type 8 Smoke Detector 2037
Type 9 RESERVED
Type A Dual Tech.
2039
Type B RESERVED
Type C Window/Door, 4 Pt.
2041
Type D PIR
2042
Type E Smoke Detector
2043
Type F Napco Glass Break
2044
ADDR
RF SUPERVISORY TIMERS
DATA ENTRIES DELAY
3 90 min.
4 120 min.
5 150 min.
6 180 min.
7 210 min.
8 240 min.
9 270 min.
0 300 min.
B 330 min.
C 360 min.
D 390 min.
E 420 min.
450 min. F
To Next Page
